Catchweight Coils
OVERVIEW:
OKBRAND manufactures a wide assortment of catchweight coils for numerous applications. Available in both black annealed or galvanized, and in several different gauges, you are sure to find the coil to meet your needs. Whether on the farm or in the shop, OKBRAND Catchweight Coils can handle the job.
SPECIFICATIONS:
| CATCH WEIGHT COILS – BLACK ANNEALED | ||||||
| ITEM # | PRODUCT | WIRE GAUGE | LENGTH | APPROXIMATE WEIGHT | COILS PER PALLET | TAG COLOR |
| 0586-0 | 9-Ga. Coil | 9 | 170′ | 10 lbs. | 1 | |
| 0592-0 | 12-Ga. Coil | 12 | 340′ | 10 lbs. | 1 | |
| 0602-0 | 14-Ga. Coil | 14 | 584′ | 10 lbs. | 1 | |
| 0585-8 | 8-Ga. Coil | 8 | 1,425′ | 100 lbs. | 1 | |
| 0588-0 | 9-Ga. Coil | 9 | 1,701′ | 100 lbs. | 1 | |
| 0591-4 | 10-Ga. Coil | 10 | 2,053′ | 100 lbs. | 1 | |
| 0591-9 | 11-Ga. Coil | 11 | 2,577′ | 100 lbs. | 1 | |
| 0593-0 | 12-Ga. Coil | 12 | 3,400′ | 100 lbs. | 1 | |
| 0598-0 | 12.5-Ga. Coil | 12.5 | 3,817′ | 100 lbs. | 1 | |
| 0603-0 | 14-Ga. Coil | 14 | 5,846′ | 100 lbs. | 1 | |
| CATCH WEIGHT COILS – GALVANIZED | ||||||
| ITEM # | PRODUCT | WIRE GAUGE | LENGTH | APPROXIMATE WEIGHT | COILS PER PALLET | TAG COLOR |
| 0589-0 | 9-Ga. Coil | 9 | 170′ | 10 lbs. | 1 | |
| 0591-3 | 10-Ga. Coil | 10 | 205′ | 10 lbs. | 1 | |
| 0591-6 | 11-Ga. Coil | 11 | 257′ | 10 lbs. | 1 | |
| 0594-0 | 12-Ga. Coil | 12 | 340′ | 10 lbs. | 1 | |
| 0604-0 | 14-Ga. Coil | 14 | 584′ | 10 lbs. | 1 | |
| 0605-5 | 17-Ga. Coil | 17 | 1,285′ | 10 lbs. | 1 | |
| 0590-0 | 9-Ga. Coil | 9 | 425′ | 25 lbs. | 1 | |
| 0591-0 | 9-Ga. Coil | 9 | 1,701′ | 100 lbs. | 1 | |
| 0591-5 | 10-Ga. Coil | 10 | 2,053′ | 100 lbs. | 1 | |
| 0591-8 | 11-Ga. Coil | 11 | 2,577′ | 100 lbs. | 1 | |
| 0595-0 | 12-Ga. Coil | 12 | 3,400′ | 100 lbs. | 1 | |
| 0605-0 | 14-Ga. Coil | 14 | 5,846′ | 100 lbs. | 1 | |
| 0605-9 | 17-Ga. Coil | 17 | 12,850′ | 100 lbs. | 1 | |
